54749247 Air/Oil Separator Filter Cartridge 22436331 for Compressor Replacement Part Maintenance Kit UP6

54749247=22436331 Oil Separator Filter Cartridge for Compressor Replacement Part Outer Diameter:135 mm,Height:302mmEnsure That Maintenance Personnel Are Properly Trained, Competent And Have Read The SSR UP6 Operation And Maintenance Manual.SEPARATOR CARTRIDGE CHANGE PROCEDURE1. Stop The Machine, Electrically Isolate And Vent All Trapped Pressure.2. Loosen Separator Cartridge With The Correct Tool.3. Remove The Cartridge from The Housing; Place It In A Sealed Bag And Dispose Of It Safely.4. Clean The Mating Face of The Housing.5. Remove The New HPPAMZ Replacement Cartridge From Its Protective Package.6. Apply A Small Amount of Lubricant To The Cartridge Seal.7. Screw The New Cartridge Down Until The Seal Makes Contact With The Housing, Then Hand Tighten A Further Half Turn.8. Start The Compressor And Check For Leaks9.Reset The Maintenance Filters Kit Service Warning.

• 54749247=22436331 Air Oil Separator Filter Cartridge .
• Better Compressor Performance: Hppamz Parts Are Rated To Provide The Highest Efficiency And Will Keep Your Air Compressor Performing At An Optimal Level.
• Enhanced Reliability: Hppamz Parts Meet Exact Equipment Specifications And Are Backed By Rigorous Testing.
• Reduce Component Damage: Helps Reduce The Risk Of Damage To Expensive Compressor Components.
• Lower Cost of Ownership: Hppamz Parts Will Perform To The Original Factory Specification.
